Description
- Brand Name: pobod
- Certification: CE
- Certification: FCC
- Certification: RoHS
- Origin: CN(Origin)
- Length: 12inch
- Model Number: SW-14-2-12
- Package: Yes
- Type: Laptop Docking Stations
- Material: Aluminum
- Width: 5inch
- Color: Silver
- Material: Aluminum alloy
- Size: 260mm*80mm*(16mm, 8mm)/10.24*3.15*(0.62, 0.31)inch
- Interface: USB Type C male port
- Port-1: USB 2.0, Type A Female Port
- Port-2: SD Card Slot
- Port-3: Micro SD Card Slot, TF Card Slot
- Port-4: USB 3.0, Speed up to 5Gbps
- Port-5: USB Type C Female Port for Data Transmission
- Port-6: USB 3.0, Speed up to 5Gbps
- Port-7: Ethernet Network Adapter RJ45 Port, 10/100Mbps, NOT support 1000Mbps
- Port-8: HDMI max support 4K 30Hz
- Port-9: HDMI max support 4K 30Hz
- Port-10: DC 3.5mm Audio Jack Port
- Port-11: VGA max support 1080P 60Hz
- Port-12: USB Type C PD Charging Port
- Function-1: Connect Keyboard, Mouse, USB Flash, Printer etc.
- Function-2: Support MST
Laptop Dock Dual HDMI Dual Screen Dual Display Adapter Hub, USB Type C Laptop Docking station For Lenovo ThinkPad HP Dell XPS
USB C Docking Station Specifications:
*********************************************************
12-IN-1 Docking Station
Color: Gray
Material: Aluminum alloy
Size: 274mm*80mm*(16mm, 8mm)/10.79*3.15*(0.62, 0.31)inch
Length of Cable: 290mm/11.42inch
Interface: USB Type C male port
Port-1: USB 2.0, Type A Female Port
Port-2: SD Card Slot
Port-3: Micro SD Card Slot, TF Card Slot
Port-4: USB 3.0, Speed up to 5Gbps, Power Supply Up to 5V-900mA 4.5W
Port-5: USB Type C Female Port for Data Transmission, Speed up to 5Gbps, Power Supply Up to 5V-900mA 4.5W
Port-6: USB 3.0, Speed up to 5Gbps, Power Supply Up to 5V-900mA 4.5W
Port-7: Ethernet Network Adapter RJ45 Port, 10/100Mbps, NOT support 1000Mbps
Port-8: HDMI max support 4K 30Hz, Downwards Compatible with 1080P, 720P etc.
Port-9: HDMI max support 4K 30Hz, Downwards Compatible with 1080P, 720P etc.
Port-10: DC 3.5mm Audio Jack Port
Port-11: VGA max support 1080P 60Hz, Downwards Compatible with 1080I, 720P etc.
Port-12: USB Type C PD Charging Port
*********************************************************
4-IN-1 Specifications
Color: Gray
Material: Aluminum alloy
Size: 58mm*52mm*12mm/2.28*2.05*0.47inch
Length of Cable: 100mm/3.94inch
Interface: USB Type C male port
Port-1: HDMI max support 4K 30Hz, Downwards Compatible with 1080P, 720P etc.
Port-2: HDMI max support 4K 30Hz, Downwards Compatible with 1080P, 720P etc.
Port-3: USB Type C PD Charging Port
Port-4: USB 3.0, Speed up to 5Gbps, Power Supply Up to 5V-900mA 4.5W
*************************************************
Function-1: Connect Keyboard, Mouse, USB Flash, Printer etc.
Function-2: Easy to Read Digital Camera Storage SD, Micro SD, TF Card
Function-3: Connect Lan via RJ45, Enjoy more reliable network than wireless
Function-4: Support USB C Power Delivery, Keep laptop the best performance
Function-5: Extend a Larger Screen via HDMI or VGA
Function-6: Connect Projector, Monitor, HD-TV, HDMI up to 4K 3840×2160 30Hz
Function-7: 2 HDMIs and VGA, Support Mirror Mode and Extended Mode
Function-8: Support MST, Extend mode support Extend 2 monitors to show different contents on Windows
*********************************************************
Package Contents: 1*USB C Docking Station
ONLY 1 Docking station in the package, other accessories are not included.
*********************************************************
Compatible:
* For MacBook 2018/2017, MackBook Pro 2018/2017
* For Lenovo ThinkPad T490, T490s, T14 (14")Intel, T480, T480s, T580, T590, T15 (15")Intel
* For Lenovo ThinkPad P43s (14"), P14s (14"), P15s (15")
* For Lenovo ThinkPad X280, X390, X13(13")Intel, X13 Yoga(13"), X380 Yoga(13")
* For Lenovo ThinkPad X1 Yoga Gen 3 (14"), X1 YOGA Gen 4 (14"), X1 Yoga Gen 5 (14")
* For Lenovo ThinkPad X1 Carbon Gen 6 (14"), X1 Carbon Gen 7 (14"), X1 Carbon Gen 8 (14")
* For Dell XPS 13 9360, XPS 13 9370, XPS 13 9380, XPS 13 7390, XPS 13 9300
* For Dell XPS 13 9365 2-in-1, XPS 13 7390 2-in-1
* For Dell XPS 15 9575 2-in-1
* For Dell Latitude 7400 2-in-1 14"
* For Dell Latitude 7200 2-in-1 12", Latitude 7210 2-in-1 12"
* For HP SPECTRE x360 15.6'', HP SPECTRE x369 13''
* For Surface Book 2
* updating…
The other windows laptops MUST require:
– The USB-C port on your laptop is a Thunderbolt-3 port.
– The USB-C port of the laptop is also a AC(power) port, or you don't want to power the laptop via this docking station.
WARNING TIPS:
1. If you are not sure whether this docking station is compatible with your laptop,
please tell me the model of your laptop, I am pleasure to check the compatible.
2. You MUST make sure the host USB-C port is on the left side of your laptop.
Because the length of cable maybe not enough to connect USB-C port in the right side when placing this Docking station under the laptop.
Or you don't want to place this docking station under the laptop.
3. 4Kx2K@30Hz support on ONLY one HDMI is connecting, the other HDMI and VGA is disconnecting.
4. When you use the docking station to extend monitors, please connect to monitors first, and then connect to your laptop.
Not support HDMI and VGA Hot plug.
